Description
Brass Brake Blanking Cap M12 x 1mm Female
Solid brass female blanking cap with an M12 x 1mm internal thread and no pipe hole. Screws onto an M12 x 1 male port or hose end to seal it – clutch and brake hoses and lines being stored. Supplied by EMS Spares, Leicester – over 30 years in automotive components.
Specification
| Thread | M12 x 1mm female (1mm pitch) |
|---|---|
| Type | Female blanking cap (solid) |
| Hex / spanner size | N/A |
| Overall length | N/A |
| Material / finish | Solid brass, natural finish – rust resistant, will not seize |
| Interchange reference | HU15AB* |
| EMS part number | EMS-A15AB |
* Reference numbers are for identification and cross-reference only. EMS Spares is an independent UK supplier and has no connection with the owners of these part numbers. All dimensions are approximate.
Buyer’s guide: brake blanking plugs and caps explained
What does a blanking cap do?
A blanking plug or cap seals a brake or clutch port, pipe end or hose that is not in use – for example a spare outlet on a master cylinder or T-piece, a removed pipe while you work, or a system being stored. It seals by seating against the flare seat of the port, in the same way a union clamps a pipe flare, so the thread must match exactly.
Step 1 – identify your thread (the most common mistake)
| Thread | Outside diameter (male part) | Threads | Typically found on |
|---|---|---|---|
| M10 x 1mm | 10mm approx | 1mm pitch (about 25 per inch) | Most European and Japanese cars, many later British cars and kit cars |
| M10 x 1.25mm | 10mm approx | 1.25mm pitch | Some older Italian and French cars (e.g. Fiat, Lancia) |
| 3/8″ x 24 UNF | 9.5mm approx | 24 per inch | Most British classics: MG, Triumph, Mini, Land Rover Series |
| M12 x 1mm (this part) | 12mm approx | 1mm pitch | Larger ports, some master cylinders and 1/4″ pipe |
Tip: M12 x 1 is the larger metric brake thread (12mm across the male thread) – do not confuse it with M12 x 1.25 or 1/2″ x 20 UNF. Check the pitch with a thread gauge.
Step 2 – cap or plug?
- Female blanking cap (this part): screws onto an M12 x 1 male port or hose end.
- Male blanking plug: screws into an M12 x 1 female port – see our EMS-A9B.
How to fit – good practice
- Clean the male port and check the end is free of dirt.
- Start the cap by hand for several turns – it should turn freely.
- Tighten until it seats firmly, holding the hose with a second spanner so it does not twist.
- Check for leaks with the pedal pressed hard.
Safety: brakes are a safety-critical system. If you are not confident, have the work done or checked by a qualified mechanic.
Pack sizes
Available as 2, 3, 4 or 5 caps. Larger packs cost less per piece.
Delivery
Free UK delivery on every order (including Northern Ireland, Highlands & Islands). Same-day dispatch on orders placed before 10am.
Trusted by thousands of buyers on eBay
99.9% positive feedback from over 9,700 ratings, and 5.0 out of 5 for accurate description, postage cost, delivery time and communication (last 12 months). Read our eBay feedback.
FAQ
Is M12 x 1 the same as 1/2″ UNF? No. They look similar but the threads are different and will bind.
Why brass? Brass does not rust or seize, so the blank can be removed again later.
Will it fit a clutch hose end? Yes, where the hose end is an M12 x 1 male thread.
Need help? Message us with your vehicle and the part you are connecting to and we will confirm the right fitting before you order.
